Hima HIMATRIX Safety-Related Controller F60DI3201 F60 DI 32 01

Brand:HIMA
Model:F1DI16 01 F1DI1601
Module Type:Safety-Related Controller
Input Voltage Range:12 to 30 VDC
Output Voltage Range:0 to 30 VDC
Number of Inputs:16
Number of Outputs:16
Operating Temperature:-25°C to +85°C
Storage Temperature:-40°C to +85°C
Certification:CE, UL, TÜV

Product Description:
The Hima HIMATRIX F60DI3201 is a safety-related controller designed for use in critical industrial applications. Part of the HIMATRIX series, this module offers high reliability and flexibility for managing safety functions in automation systems.
The safety-related F1 DI 16 01 remote I/O is a compact system in a metal housing with 16 digital inputs and 4 pulsed outputs.

Safety Function:
The remote I/O is equipped with safety-related inputs. The input values on the inputs are safely
transmitted to the connected controller via safeethernet.

Safety-Related Digital Inputs:
The remote I/O is equipped with 16 digital inputs. The state (HIGH, LOW) of each input is
signaled by an individual LED.
Mechanical contacts without own power supply or signal power source can be connected to the
inputs. Potential-free mechanical contacts without own power supply are fed via an internal short-circuit-proof 24 V power source (LS+). Each 24 V power source supplies a group of 4 mechanical contacts.

Reaction in the Event of a Fault:
If the device detects a fault on a digital input, the user program processes a low level in accordance with the de-energized to trip principle.
The device activates the FAULT LED.
In addition to the channel signal value, the user program must also consider the corresponding error code.
The error code allows the user to configure additional fault reactions in the user program.
