330102-00-28-05-02-00 Bently Nevada Proximity Probes

February 22,2025

Introduction to the 3300 XL 8 mm Probe
The 330102-00-28-05-02-00 3300 XL 8 mm probe is a crucial component in proximity transducer systems, widely used for monitoring machinery vibration and position. Designed for precision and reliability, this probe offers unparalleled performance in fluid-film bearing machines and other industrial applications. In this guide, we will explore its specifications, configurations, and benefits.

Key Specifications and Features
The 330102-00-28-05-02-00 3300 XL 8 mm probe is engineered to meet rigorous industry standards. Some of its standout specifications include:
Thread Type: 3/8-24 UNF
Unthreaded Length: Customizable from 0.0 in to 8.8 in
Case Length: Adjustable from 0.8 in to 9.6 in
Total Length Options: Ranges from 0.5 meters (1.6 feet) to 9.0 meters (29.5 feet)
Compliance: Meets API 670 (4th Edition) standards for accuracy and stability
These features make the 3300 XL 8 mm probe an ideal choice for various monitoring applications.

Configurations and Customization Options
To cater to different industrial needs, the probe offers multiple customization options:
Unthreaded Length Option
Users can order in increments of 0.1 inches, with options ranging from 0.0 in to 8.8 in. For example, selecting "0 4" results in an unthreaded length of 0.4 inches.

Overall Case Length Option
The case length is also configurable in increments of 0.1 inches, allowing for variations between 0.8 in and 9.6 in. For instance, "2 4" translates to a case length of 2.4 inches.

Total Length Option
Customers can choose from various length options, including:
0.5 meters (1.6 feet)
1.0 meter (3.3 feet)
1.5 meters (4.9 feet)
2.0 meters (6.6 feet)
3.0 meters (9.8 feet)
5.0 meters (16.4 feet)
9.0 meters (29.5 feet)
These length options provide flexibility for different machine setups and monitoring requirements.

System Components and Functionality
The 330102-00-28-05-02-00 3300 XL 8 mm Proximity Transducer System is composed of:
3300 XL 8 mm Probe
3300 XL Extension Cable
3300 XL Proximitor Sensor

Together, these components ensure accurate measurements of both static (position) and dynamic (vibration) parameters. The system generates an output voltage proportional to the distance between the probe tip and the conductive surface, making it a reliable choice for machine monitoring.

Compatibility and Compliance
One of the significant advantages of the 330102-00-28-05-02-00 3300 XL 8 mm probe is its compatibility with other components in the 3300 series. It offers full interchangeability with:
Non-XL 3300 series 5 mm and 8 mm transducer systems
3300 5 mm probe for applications requiring a smaller mounting space
This compatibility eliminates the need for bench calibration and ensures seamless integration with existing monitoring systems.

Conclusion

The 330102-00-28-05-02-00 3300 XL 8 mm probe is a highly versatile and reliable component in industrial vibration and position monitoring. With its customizable configurations, compliance with API 670 standards, and full interchangeability, it is a top choice for fluid-film bearing machines and other critical applications. Whether you need precise vibration analysis or keyphasor reference measurements, this probe delivers consistent and accurate performance.
