Product Specifications

Product Model	2711P-RDT12H
Display Size	12.1 inches
Display Area	246×184 mm
Resolution	800×600
Display Color	18-bit color
Luminance	1000 cd/m²
Input Type	Touch screen
Anti-Glare Film	Not equipped
Touch Type	8-wire analog resistive
Touch Lifespan	1 million actuations
Actuation Force	10-110 g
Compatible Model	1250 Terminal
Input Voltage	24 VDC
Max Power Consumption	70 W

The 2711P-RDT12H is a PanelView operator terminal component that is specifically used for operator terminals with High Bright display. This PanelView is compatible for use with PanelView Plus and PanelView Plus 6 1250 High-Bright displays. It is designed with a high luminance of 1000 cd/m2 (Nits.). With this High-bright display, compatible PanelView that uses this component may be installed in outdoor locations.
The 2711P-RDT12H comes with an integrated temperature sensor that is used to monitor the temperature of the operator terminal. This temperature sensor enables automatic adjustment of brightness. The 2711P-RDT12H display module may be used DC boards only.

Frequently asked questions：

Q1:Is the 2711P-RDT12H High-Bright Display Module's module replaceable?
A1:Yes, if the replacement logic module has the following replacement part number: 2711P-RP2.

Q2:What is the backlight replacement number for the 2711P-RDT12H Display Module?
A2:The 2711P-RDT12H PanelView Plus Display Module does not have a replacement part.

Q3:What is the rated luminance of the 2711P-RDT12H?
A3:The 2711P-RDT12H has a luminance rating of 1000 cd/m2 (Nits).

Q4:Does the High-bright module come with communication interfaces?
A4:No. The high-bright display module is simply the visualization interface. The communication interfaces are purchased separately.

Q5:Does this module feature an automatic adjustment of brightness?
A5:Yes. The internal temperature sensor triggers the automatic adjustment of brightness when hardware temperature exceeds the rated operating temperature.

Product Applications

Offshore oil/gas platforms and petrochemical plants
Metal smelting and steel mills
Large-scale water treatment and sewage treatment plants
Building materials and cement plants
