Product Specifications

Part Number	DDM3U-1-320V-30A-S
Bus Input Voltage	24 V DC ~ 320 V DC
Continuous Output Current	30 A (RMS)
Peak Output Current	60 A (max duration 1 second)
Control Supply Voltage	24 V DC ± 10%
Maximum Output Power	Up to 9.6 kW
PWM Switching Frequency	20 kHz / 40 kHz (selectable)
Operating Temperature	0°C ~ +50°C
Storage Temperature	-20°C ~ +70°C

The ACS DDM3U-1-320V-30A-S Universal Drive is a high-performance motion control solution for demanding industrial and servo drive applications. It supports a wide bus input voltage range from 24 V DC to 320 V DC, providing exceptional flexibility for integration into various power systems. The drive delivers a continuous output current of 30 A (RMS) and can provide peak currents of up to 60 A for one second, ensuring reliable performance during dynamic load conditions and rapid acceleration. With a maximum output power of up to 9.6 kW, the DDM3U-1-320-30-SR is suitable for controlling a wide range of motors in precision motion applications. The unit operates from a 24 V DC control supply with a tolerance of ±10% and features selectable PWM switching frequencies of 20 kHz or 40 kHz, enabling smooth motor operation and optimized system performance. It operates reliably within a temperature range of 0°C to +50°C and can be safely stored between -20°C and +70°C.

Frequently asked questions：

Q1: What is the ACS DDM3U-1-320V-30A-S Universal Drive used for?
A1: The ACS DDM3U-1-320V-30A-S Universal Drive is a high-performance servo drive used to control DC brushless, AC servo, and other compatible motors.

Q2: What is the bus input voltage range of the DDM3U-1-320V-30A-S drive?
A2: The DDM3U-1-320V-30A-S drive supports a bus input voltage range of 24 VDC to 320 VDC, providing flexibility for a wide range of DC power systems.

Q3: What is the DDM3U-1-320V-30A-S continuous output current rating?
A3: The ACS DDM3U-1-320V-30A-S delivers a continuous output current of 30 A RMS, ensuring stable operation during continuous-duty applications.

Q4: What is the DDM3U-1-320V-30A-S peak output current capability?
A4: The DDM3U-1-320V-30A-S drive provides a peak output current of 60 A for up to 1 second, allowing it to handle high starting torque and short-term overload conditions.

Product Applications

Semiconductor and electronics manufacturing plants
Display panel (FPD) and OLED manufacturing plants
Laser processing and precision CNC plants
Medical and life science equipment plants

Grab an Extra Discount - Contact Sales Manager Lisa Lin Today :
:sales7@amikon.cn :+86-18965423501 :AMKPLC

We provide a 12-month warranty and worldwide stock availability to guarantee smooth integration and prompt delivery for your daily operations.
