Product Infor
Origin: Austria Brand name: Bachmann Model:ISI222 Warranty period: 1 year Minimum order quantity: 1 piece	Delivery time: 1-3 days Transportation period: DHL FEDEX EMS UPS TNT Condition: 100% original brand Payment method: T/T Quality: 100% original and 100% brand

Describtion

The positioning module ISI222 is designed specifically for complex motion control applications, achieving high device compactness and maximum accuracy. Directly embedded with several encoder interfaces for position detection, analog output terminals for applying adjustment quantities, and digital input terminals for starters or triggers, it can comprehensively control two motion axes. In addition, the central communication concept enables all inputs/outputs of the remaining M1 systems to be integrated into motion control (limit switches, etc.).

Key Infor

2 input channels for incremental and SSI encoders
Full 32-bit counter
2-channel analog output (14 bits)
4 high-speed digital input channels for starters and triggers
Measure and store location through triggers
Virtual inputs that can be used in applications: zero pulse and velocity
Synchronize through SYNC/PreSYNC
Supply power to the encoder through the module
Monitor encoder voltage
Disconnected monitoring (encoder)
Encoder power supply
The output voltage range can be selected by jumper+5 V and+15 V, through a 24 V circuit
Output voltage+5 V+15 V -1 V
Tolerance ± 5% ± 3% is the same as Uext
Maximum current/encoder 250 mA 100 mA 300 mA
Short circuit protection is permanent, permanent, permanent (PTC)
Ripple<150 mVSS at+5 V and+15 V
Electrical isolation between channels at 500 V
Analog Output
Quantity 2
Output voltage ± 10 V
Resolution 14 bits
Maximum output current ± 2 mA
Conversion time<40 µ s
Basic accuracy at 25 ° C 0.025%
The error of the entire temperature range is ± 0.1%
The starting time reaches 1% of the output range, with a maximum of 500 µ s
