Power Supply: –17.5 Vdc to –26 Vdc
Sensitivity: < 2 mV
Output Resistance: 50 Ω
Recommended Gap Setting: –9 Vdc
Incremental Scale Factor (ISF): 7.87 V/mm (200 mV/mil) ±5%
Extension Cable Capacitance: 69.9 pF/m (21.3 pF/ft) typical
Field Wiring: 0.2–1.5 mm² (16–24 AWG)
Linear Range: 2 mm (80 mils)
Minimum Target Size: 15.2 mm (0.6 in)

The 3300 XL 8 mm system delivers the most advancedperformance in our eddy current proximity transducersystems.The standard 3300 XL 8 mm 5-meter system alsofully complies with the American Petroleum institute's (APl)670 Standard for mechanical configuration, linear range,accuracy,and temperature stability.All 3300 XL 8 mmproximity transducer systems provide this level ofperformance and support complete interchangeability ofprobes, extension cables, and Proximitor sensors, eliminatingthe need to match or bench calibrate individual components.
