Product Model	330180-X1-05 MOD：145004-09
Incremental Scale Factor (ISF)	7.87 V/mm (200 mV/mil)
Linear Range	2.0 mm (80 mils)
Supply Voltage	-23.5 Vdc ~ -24 Vdc
Current Consumption	Less than 12 mA
Operating Temperature Range	-40°C ~ +85°C (-40°F ~ +185°F)
Storage Temperature Range	-51°C ~ +105°C (-60°F ~ +221°F)
System Length ( 05)	5.0 meters
Mounting Option ( X1)	35mm DIN Rail Mount

The 3300 XL 8 mm system delivers the most advanced performance in our eddy current proximity transducer systems. The standard 3300 XL 8 mm 5-meter system alsofully complies with the American Petroleum Institute's (APl)670 Standard for mechanical configuration, linear range,accuracy, and temperature stability. All 3300 XL 8 mmproximity transducer systems provide this level of performance and support complete interchangeability ofprobes, extension cables, and Proximitor sensors, eliminatingthe need to match or bench calibrate individual components.

Each 3300 XL 8 mm Transducer System component isbackward compatible and interchangeable4 with other non-XL 3300 series 5 mm and 8 mm transducer systemcomponents5. This compatibility includes the 3300 5 mmprobe, for applications in which an 8 mm probe is too largefor the available mounting space6,7.

Frequently asked questions：

Q1: What does "MOD:145004-09" mean?
It means the sensor is factory-calibrated for ASTM A276 Type 410 Stainless Steel targets. Standard models only read AISI 4140 carbon steel. Using a standard sensor on a 410 stainless shaft causes severe measurement errors.

Q2: Can I use this 5.0m sensor with a 9.0m probe or cable?
No. The -05 suffix locks the internal tuning to a 5.0-meter total loop length. You must use a matching 5.0m probe and cable combination (e.g., 1.0m probe + 4.0m cable) to prevent scale factor distortion.

Q3: Does the "X1" option require external mounting insulation?
No. The X1 housing has a built-in, electrically isolated 35mm DIN rail clip. It snaps directly onto standard metallic rails without risking electrical ground loops.

Q4: Why is my sensor's linear range compressed during testing?
Check your input voltage. The system requires a stable -23.5 Vdc to -24 Vdc supply. If the voltage drops closer to -18 Vdc, the sensor stays on but its linear tracking window contracts.
