Product Specifications

Manufacturer	Bently Nevada
Product No.	43501-01-04-01
Product Type	Low Pressure Cable Seal
High Pressure Side Thread Size (01)	1/2-14 NPT
Cable Grommet and Washer (04)	Grommet will accommodate up to 4 cables. One hole is punched and three are partially pre-drilled.
Low Pressure Side Thread Size (01)	1/2-14 NPT
Shipping Weight	3 Kg

The 43501 Low-Pressure Cable Seal provides egress for up to 4 750 and/or 9503300XL, 3300 and 7200 cables, or up to 2 25mm DE or 50mm DE transducercables, through a single hole in a machine case or other barrier.

The cable seal is constructed of 303 stainless steel and a molded silicon rubbergrommet and prevents leakage of fluids along the outer jacket of the cable. Theseal has threads on both ends and fits into a tapped hole on the machine caseor barrier. External pipe threads enable the seal to mate to conduit or housings.

You can use the low-pressure cable seal only with non-armored cables. Itsdesign seals pressures up to 345 kPa (50 psil when properly installed.

Frequently asked questions：

Q:What specific thread sizes are featured on the 43501-01-04-01 cable seal?
A:The "01" suffix codes indicate that both the high-pressure side and the low-pressure side of the 43501-01-04-01 feature a standard 1/2-14 NPT pipe thread size.

Q:How many sensor lines can the grommet on the 43501-01-04-01 accommodate out of the box?
A:The "04" option specifies that the silicone rubber grommet is configured for up to 4 cables; it arrives with one hole completely punched and three holes partially pre-drilled for immediate site deployment.

Q:What is the maximum pressure limit for the 43501-01-04-01 assembly when properly installed?
A:The 43501-01-04-01 is engineered to withstand low-pressure industrial boundary conditions up to a maximum of 345 kPa (50 psi) across the grommet assembly.

Q:Can the 43501-01-04-01 be paired with stainless steel armored proximity probe cables?
A:No. The 43501-01-04-01 is strictly specified for use with non-armored coaxial transducer cables, as it relies on compressing directly against a smooth cable outer jacket to form a fluid-tight seal.
