Product Specifications

Model Number	HIMAX X-AO1601
Nominal range	4…20 mA
Operating range	0…22.5 mA
Digital resolution	16-bit (10 000 digits in SILworX)
Value of LSB	≤ 2 µA
Ohmic load	max. 600 Ω
Inductive load	max. 1 mH
Capacitive load	max. 100 µF in parallel to the ohmic load
Settling time	5 ms
Shutdown time if a fault occurs	16 ms
Linearity error, max.	≤ ± 0.1 %
Safety-related accuracy	≤ ± 2 % of final value
Stripping length	6 mm
Screwdriver	Slotted 0.4 x 2.5 mm
Tightening torque	0.2…0.25 Nm

Frequently asked questions：

Q1: What is the HIMA HIMAX X-AO1601?
A1: The X-AO1601 is an analog output module for HIMA HIMAX safety systems, designed to deliver precise current signals to actuators and field devices in safety-critical applications.

Q2: What is the X-AO1601 nominal output range?
A2: The X-AO1601 nominal output range is 4…20 mA, which is standard for industrial analog signal transmission.

Q3: What is the X-AO1601 operating range?
A3: The X-AO1601 module supports an extended operating range of 0…22.5 mA.

Q4: What is the X-AO1601 digital resolution?
A4: It features 16-bit resolution (10,000 digits in SILworX), ensuring high precision in signal output.

Q5: What is the X-AO1601 value of the least significant bit (LSB)?
A5: The LSB value is ≤ 2 µA, allowing fine-grained output adjustments.

Product Applications

Oil & Gas
Chemical & Petrochemical
Power Generation
Pharmaceutical & Fine Chemical
