brand new IC695ALG608 GE Non-isolated analog input module,IC695ALG608 GE Non-isolated analog input module suppliers,IC695ALG608 GE Non-isolated analog input module manufacturers,factories

Brand	GE Fanuc
Series	PACSystem RX3i
Manufacturer	Emerson Automation
Manufacturer	GE Intelligent Platforms (Former); Emerson Automation (Current)
Part Number	IC695ALG608
Product Description	Non-isolated analog input module
Series	PACSystem RX7i
Module Type	Analog Input
No of Channels	Eight (8) non-isolated, single-ended; Four (4) non-isolated, differential
Part Number	IC695ALG608
Number of Inputs	8 single-ended or 4 differential input channels
Input signals, Current	0-20 mA; 4-20 mA; +/-20 mA;
Product Description	Analog input module
Current Range	0-20 mA, 4-20 mA, +/-20 mA
Humidity	5 to 95%, non-condensing
Programmer Version	Machine Edition version 5.0 SP3 and later
Open Circuit Detection time	1 second maximum

The IC695ALG608 is an analog input module from the PACsystem RX3i platform. This module is able to provide up to Eight (8) input channels when configured for single-ended wiring and Four (4) input channels for differential input wiring. It supports a variety of input signals such as +/-10 VDC, 0-10 VDC, +/- 5VDC, 0-5 VDC, 1-5 VDC and 0-20 mA, 4-20 mA and +/- 20mA input signals with built-in 24-bit Analog to Digital Converter (ADC) that translates received analog data to either integer or floating point data. The IC695ALG608 is installed to an RX3i universal backplane. It occupies a single slot of the rack with current draw 330 mA maximum @ 5.0V +5% / -2.5% and 600 mA maximum @ 3.3V +5% / -3%. This module is used with an RX3i Central Processing Unit (CPU) firmware version 3.0 or later and configured using Machine Edition version 5.0 SP3 and later. Available filter options for each input channel includes 8Hz, 12Hz, 16Hz, 40Hz, 200Hz, 500Hz which are mainly used to normalize analog readings and eliminate rapid fluctuations. The IC695ALG608 is compatible for use with a variety of terminal blocks such as Box-style (IC694TBB032), Extended Box-style (IC694TBB132), Spring-style (IC694TBS032), or Extended Spring-style (IC694TBS132) terminal Block. This module does not have external jumpers for setting module operation instead, parameters are defined via software configurable parameters. In addition, this module features full-autocalibration, on-board error checking, open circuit detection, alarm settings, module fault reporting, interrupts for channel alarm and fault and other equally important features.
