Model Number: GS2107-WTBD
Power Supply Voltage: 24 VDC (+10%, -15%), ripple voltage 200 mV or less
Power Consumption: 6.5 W (271 mA / 24 V) or less
Power Consumption (Backlight Off): 3.8 W (158 mA / 24 V) or less
Inrush Current: 17 A or less (6 ms, ambient temperature 25°C, maximum load)
Allowable Momentary Power Failure Time: Within 5 ms
Noise Immunity: Conforms to IEC61000-4-4, 2 kV (power supply line)
Withstand Voltage: 350 VAC for 1 minute between power supply and ground
Insulation Resistance: 10 MΩ or higher (tested with insulation resistance tester)
Display Device: TFT color LCD
Screen Size: 7"

The GS2107-WTBD-N features a 7-inch WVGA TFT color display with a resolution of 800 × 480 pixels, capable of displaying 65,536 colors. Its analog resistive touch panel ensures reliable input, with a minimum key size of 2 × 2 dots and a durability of over 1 million touches. The unit operates on a 24V DC power supply and is protected with an IP65F rating, making it suitable for use in harsh industrial environments.
