Product Specifications

Part Number	CA202 144-202-000-205
Sensitivity	100 pC/g ±5%
Dynamic measurement range	0.01 to 400 g peak
Overload capacity (spikes)	Up to 500 g peak
Linearity (0.01 to 20 g peak)	±1%
Linearity (20 to 400 g peak)	±2%
Transverse sensitivity	≤3%
Resonant frequency (nominal)	>22 kHz
Frequency response (0.5 to 6000 Hz)	±5%
Typical deviation at 8 kHz	10%
Frequency response	0.5 to 6000 Hz
Temperature range	−55 to 260°C

The CA202 is a piezoelectric accelerometer from Meggitt’s vibro-meter® product line. The CA202 sensor features a symmetrical shear-mode polycrystalline measuring element with internal case insulation in an austenitic stainless-steel case (housing).
The CA202 is fitted with an integral low-noise cable that is protected by a flexible stainless-steel protection hose (leaktight) which is hermetically welded to the sensor to produce a sealed leaktight assembly.
The CA202 piezoelectric accelerometer is available in different versions for different industrial environments: Ex versions for installation in potentially explosive atmospheres (hazardous areas) and standard versions for use in non-hazardous areas.

Frequently asked questions：

Q1: What is the Vibro-meter CA202 144-202-000-205 Piezoelectric Accelerometer used for?
A1: The CA202 Piezoelectric Accelerometer is used to measure vibration and acceleration in rotating machinery, supporting condition monitoring, machinery protection, and predictive maintenance programs.

Q2: What is the sensitivity of the CA202 accelerometer?
A2: The sensor provides a high sensitivity of 100 pC/g, enabling accurate detection of low-level vibration signals.

Q3: What is the frequency response range of the CA202 accelerometer?
A3: The CA202 has a frequency response of 0.5 Hz to 6000 Hz, making it suitable for monitoring a wide range of machine vibration frequencies.

Q4: What is the CA202 144-202-000-205 typical deviation at 8 kHz?
A4: The CA202 144-202-000-205 typical measurement deviation at 8 kHz is +10%, indicating the sensor's response characteristics near the upper end of its operating frequency range.

Q5: What is the CA202 144-202-000-205 operating temperature range of the sensor?
A5: The CA202 144-202-000-205 accelerometer operates within a temperature range of −55°C to +260°C (−67°F to +500°F), allowing reliable performance in harsh industrial environments.

Product Applications

Power Plants
Petrochemical & Refinery Factories
Hydroelectric Power Stations
Steel & Heavy Metallurgy Mills
