Vibro-meter CE281 444-281-000-111 Piezoelectric Accelerometer

Product Specifications

The CE 281 accelerometer is equipped with a centre mounted symmetrical shear mode polycrystalline element. The attached electronics eliminates the need for a charge amplifier. The integral cable between the transducer and the electronics casing is protected by a hermetic stainless steel, flexible tube.
The electronics provides a charge-to-current conversion, and the modulated current output signal allows the use of a 2-wire cable for trouble-free transmission over long distances. The system is fully protected against cooling fluids, lubricants, water, steam etc.
The sensor head of the CE281 444-281-000-111 is hermetically sealed to the internal electronic circuitry via a low-noise, shielded internal cable, which is further protected by a flexible, leak-proof protective conduit (stainless steel hose). The sensor head, protective conduit, and electronics housing are fused into a single, integral unit using gas welding, providing comprehensive corrosion resistance to coolants, lubricants, water, steam, and other potential contaminants. Both the CE281 sensor element and its internal electronics feature integral case isolation from the housing; all variants are certified for explosion protection. The accelerometer offers a measurement sensitivity of 10 µA/g and a frequency response range of 3 to 7000 Hz, capable of continuous operation across a wide temperature range of −55 to 260°C (for the sensor section) and −40 to 125°C (for the electronics section).

Frequently asked questions：

Q1: What is the Vibro-meter CE281 444-281-000-111 Piezoelectric Accelerometer used for?
A1: The CE281 Piezoelectric Accelerometer is used to measure machine vibration and acceleration in condition monitoring and machinery protection systems, helping detect mechanical issues such as imbalance, misalignment, looseness, and bearing faults.

Q2: What is the sensitivity of the CE281 accelerometer?
A2: The sensor provides a sensitivity of 10 μA/g ±5% at 120 Hz, ensuring accurate and reliable vibration measurements.

Q3: What is the dynamic measuring range of the CE281 444-281-000-111 accelerometer?
A3: The dynamic measuring range is 0.0001 g to 200 g peak (random vibration), allowing the sensor to monitor both very small and very high vibration levels.

Q4: What is the overload capacity of the CE281 444-281-000-111 sensor?
A4: The CE281 444-281-000-111 can withstand spike accelerations up to 2000 g peak, providing excellent protection against shock events and transient overload conditions.

Q5: What is the mounted resonant frequency of the CE281 444-281-000-111 accelerometer?
A5: The CE281 444-281-000-111 mounted resonant frequency is 25 kHz nominal, ensuring stable operation and accurate measurements across its specified operating range.

Product Applications

Petrochemical and Refinery Plants
Thermal and Hydropower Plants
Metallurgical and Steel Plants
Mining and Cement Plants
