WOODWARD EASYGEN-3500XT-P1 8440-2082 Genset Controller

EASYGEN-3500XT-P1 8440-2082 is manufactured by Woodward in the company’s easYgen-3000XT series. The XT series has a few updated features from the older 3000 series. A few of the new features include drop-in replacement, power measurement Class 1, editable screens, multiple interface ToolKit connectivity, and more. Full details can be found in Woodward easYgen manual 37582A
This model is a 3200XT-P1 (Package 1) version. One notable difference between the 8440-2082 and the similar 3200XT-P1-LT model is their operating temperature range. This model is rated for operating temperatures from -20 to 70 °C; the LT version is rated for -40 to 70 °C and is suitable for outdoor use. The 8440-2082 comes with a display (3100 versions do not) and is designed for front panel mounting.

Frequently asked questions：

Q1: What is the EASYGEN-3500XT-P1 8440-2082?
A1: The EASYGEN-3500XT-P1 8440-2082 is a genset controller designed to manage and protect generator sets, providing monitoring, control, and protection functions for AC power generation.
Q2: What is the EASYGEN-3500XT-P1 8440-2082 power supply requirement for this controller?
A2: It operates on 12/24 VDC and supports an operating voltage range of 8–40 VDC.
Q3: How does it measure current?
A3: The EASYGEN-3500XT-P1 8440-2082 controller uses 5 A CT (current transformer) inputs for accurate current measurement.
Q4: How does it measure voltage?
A4: It can measure voltage up to 230 VAC, suitable for most generator applications.
Q5: What nominal frequency does the EASYGEN-3500XT-P1 8440-2082 controller support?
A5: The nominal frequency is configurable for 50 Hz or 60 Hz, allowing use in different regions and generator types.

Product Applications
Critical Infrastructure: Data center backup power systems and hospitals where power stability is vital.
Industrial Plants: Power plants, oil and gas production facilities, and large-scale manufacturing "factories".
Distributed Generation: Microgrids, peak shaving operations, and distributed energy installations.
Marine & Offshore: Marine power generation and offshore platforms (meeting ABS and Lloyd's Register compliance).
Co-Generation: CHP (Combined Heat and Power) applications.

Core Capabilities
Synchronization: Automatically aligns voltage, frequency, and phase angle before breaker closure.
Load Management: Distributes active and reactive loads evenly across multiple generators.
Communication: Includes multiple ports (Ethernet, CAN, RS-485, USB) supporting protocols like Modbus TCP/RTU and SAE-J1939.
