Technical specifications for 1746-OVP16

Part Number/Catalog No.	1746-OVP16
Series	SLC 500
Module Type	Digital DC Output Module
Voltage Range	20.4-26.4 Volts DC Sink
Outputs	16
Current/Output	1.5-1 amps
Current/Module	6.4 amps
Backplane Current (5 Volts)	250 milliamps
Applications	High Current

The 1746-OVP16 is a digital I/O module designed for the SLC 500 system. It is a high-current sinking 24V DC output module, providing fused common and a blown fuse LED indicator for short-circuit protection. If the fuse blows, the LED indicator lights up. Additionally, an LED will illuminate if a processor error occurs, causing all outputs to turn off. This module is versatile and easy to integrate into custom solutions for various industrial applications. The operating voltage for this module is 20.4 – 26.4V DC (sink), and it features 16 outputs with 16 common points. The backplane current consumption is 250 mA at 5V DC and 0mA at 24V DC. The signal delay time is 0.1 ms in On-state and 1 ms in Off-state.

Each output can handle a continuous current of 1.5A at 30°C, with a maximum thermal dissipation of 6.26 W. The maximum Off-state leakage is 1 mA, and the maximum On-state voltage drop is 1V at 1A, with a 4A surge current for up to 10 ms per point. The module is equipped with color-coded removable terminal blocks (RTBs) for easy installation and maintenance. It features LED indicators to display the I/O point status. Suitable for use in clean and dry industrial environments, it operates within a temperature range of 0 to 60°C and can withstand a 30g operating shock. The module also has radiated RF immunity of 10 V/m from 30-2000 MHz and 1 V/m from 2000-2700 MHz.
