1794-IE8XOE4 High-density FLEX I/O Module

1794-IE8XOE4
1794-IE8XOE4
1794-IE8XOE4

1794-IE8XOE4 High-density FLEX I/O Module

Brand new and original sealed//Same Day Shipment

  • Country of Origin:

    USA
  • Weight:

    0.35KG
  • Dimensions:

    12cmx10cmx8cm
  • Warranty Period:

    One Year Warranty
  • Payment Term:

    100% Advance Payment T/T Bank Wire Transfer

Technical specifications for 1794-IE8XOE4

Series

Flex I/O 1794

Part Number

1794-IE8XOE4

Current

0 to 20 mA

I/O Type

Single-ended, non-isolated

Number of inputs

8

Number of outputs

4

Nominal voltage

24 Volts DC

Adjustable voltage rating

0 to 10 Volts DC

Instructions

BTW and BTR


The 1794-IE8XOE4 module is a high-density FLEX I/O module designed for analog applications in modular systems. It serves as part of a system that provides the same functionality as rack-based I/O and distributed I/O systems. In a complete FLEX I/O modular system, the 1794-IE8XOE4 module connects to a terminal base, an adapter, or a power supply. The module includes the system's bus interface and the necessary circuitry to perform all required applications. This analog FLEX I/O module allows users to adjust the voltage between 0 and 10 Volts DC and the current between 0 and 20 mA.

The 1794-IE8XOE4 high-density FLEX I/O module features 8 single-ended, non-isolated inputs and 4 single-ended, non-isolated outputs for communication. Its nominal operating voltage is 24 Volts DC. The module can communicate with programmable controllers using Block Transfer Write (BTW) and Block Transfer Read (BTR) instructions. BTW instructions enable data transfer from the controller to the module, while BTR instructions allow data to be transferred from the module back to the controller. Both instruction sets allow the controller to retrieve status updates and input values from the I/O module, as well as program the module’s operating mode. The power indicator light on the front panel provides a clear visual signal to indicate whether the 1794-IE8XOE4 module is powered on or off.
