Technical specifications for 1734-OW2

Part Number/Catalog No.	1734-OW2
Series	POINT I/O
Module Type	Digital Contact Module
Outputs	2 N.O relay
POINTBus Current	80 milliamps
Power Dissipation, Max	0.5 Watts

The 1734-OW2 POINT I/O 2 Relay Output Module is part of the digital I/O module series, offering voltage interfaces and field-side diagnostics. It features a 2-form, open electromechanical relay with an OFF-state leakage current of 1.2mA at 240V AC, thanks to a unique bleed resistor installed in the snubber circuit. The module is equipped with two relay outputs and has a 26ms delay between the OFF-state and ON-state. It provides a thermal dissipation of 1.7 BTU/hr at 0.5W and has a capacitance of 30mΩ. The POINT I/O module operates with a POINT bus current of 100mA at 5V, and it fits on the corresponding base assembly, either 1734-TB or 1734-TBS.

The 1734-OW2 has 2 normally open (N.O) relay outputs, consuming a POINT Bus current of 80 milliamps with a maximum power dissipation of 0.5 Watts. It has compact dimensions of 56.0mm x 12.0mm x 75.5mm (2.21in x 0.47in x 2.97in) and weighs approximately 32.6g (1.15oz). The module meets CISPR 11, Group 1, Class A emission standards, and is certified to withstand shocks of up to 30G as per IEC 60068-2-27. It can endure maximum vibrations of 5G at 10-500Hz. The optimal operating temperature range for the 1734-OW2 is between -20°C and 55°C (-4°F and 131°F), with a humidity tolerance tested between 5-95% relative humidity. The contact rating is 120-240V AC at 2A, with an expected electrical contact half-life of 100,000 cycles per minute. The module uses 0.25 by 2.5 mm2 (22 by 14 AWG) stranded copper wire for signal port wiring, rated for 85°C with 1.2mm (3/64 in.) insulation.
