Product Specifications

Model Number	NGDR-07C NGDR-07 FF1400R12IP4
Collector-Emitter Voltage(VCES)	1200 V
Continuous DC Collector Current(IC nom)	1400 A
Repetitive Peak Collector Current(ICRM)	2800 A
Total Power Dissipation(Ptot)	7.65 kW
Gate-Emitter Peak Voltage(VGES)	±20 V
Collector-Emitter Saturation Voltage(VCEsat)	Typ. 2.05 V
Gate Threshold Voltage(VGEth)	5.0~6.5 V
Gate Charge(QG)	9.60 μC
Internal Gate Resistor(RGint)	0.8 Ω
Input Capacitance(Cies)	82.0 nF
Reverse Transfer Capacitance(Cres)	4.60 nF
Collector Cut-Off Current(ICES)	5.0 mA

The FF1400R12IP4 is a high-power PrimePACK™3 IGBT module from Infineon, featuring advanced Trench/Fieldstop IGBT4 and Emitter Controlled 4 diode technology for superior efficiency and reliability in demanding industrial applications. Designed with a collector-emitter voltage of 1200 V and a nominal collector current of 1400 A, the module supports a repetitive peak collector current of up to 2800 A, making it ideal for high-power converters, motor drives, traction drives, UPS systems, auxiliary inverters, and wind turbine applications.

Frequently asked questions：

Q1: What is the FF1400R12IP4 IGBT module used for?
A1: It is commonly used in industrial drives, power converters, inverter systems, and high-power motor control applications.

Q2: What is the NGDR-07C NGDR-07 FF1400R12IP4 internal gate resistor value?
A2: The NGDR-07C NGDR-07 FF1400R12IP4 internal gate resistor (RGint) is 0.8 Ω, helping improve switching control and stability.

Q3: What is the NGDR-07C NGDR-07 FF1400R12IP4 input capacitance of the module?
A3: The NGDR-07C NGDR-07 FF1400R12IP4 input capacitance (Cies) is 82.0 nF.

Q4: What is the NGDR-07C NGDR-07 FF1400R12IP4 reverse transfer capacitance?
A4: The NGDR-07C NGDR-07 FF1400R12IP4 reverse transfer capacitance (Cres) is 4.60 nF, which helps determine switching characteristics.

Q5: What is the NGDR-07C NGDR-07 FF1400R12IP4 collector cut-off current of the module?
A5: The NGDR-07C NGDR-07 FF1400R12IP4 collector cut-off current (ICES) is 5.0 mA.

Product Applications

Auxiliary Inverters
High Power Converters
Motor Drives
Traction Drives
UPS Systems
Wind Turbines
