Product Specifications

Model Number	NGDR-07C NGDR-07 FF650R17IE4
Collector-Emitter Voltage	1700 V
Repetitive Peak Collector Current	1300 A
Total Power Dissipation	4.15 kW
Gate-Emitter Peak Voltage	±20 V
Gate Charge	7.00 μC
Internal Gate Resistor	2.3 Ω
Input Capacitance	54.0 nF
Reverse Transfer Capacitance	1.70 nF
Collector-Emitter Cut-off Current	5.0 mA
Gate-Emitter Leakage Current	400 nA

The FF650R17IE4 is a high-performance PrimePACK™2 IGBT module developed for demanding industrial power conversion applications. Designed with a collector-emitter voltage of 1700 V and a nominal collector current of 650 A, the module also supports a repetitive peak collector current of up to 1300 A, delivering outstanding power handling capability for high-load operations. It is widely used in 3-level applications, auxiliary inverters, high-power converters, motor drives, and wind turbine systems.
This module features advanced electrical performance, including low switching losses, low VCEsat characteristics, high current density, and high DC stability, ensuring improved energy efficiency and reliable operation even in harsh industrial environments. With an extended junction operating temperature of up to 150°C and a total power dissipation of 4.15 kW, the FF650R17IE4 offers excellent thermal performance and long-term operational stability.

Frequently asked questions：

Q1: What is the FF650R17IE4 IGBT module used for?
A1: It is used in industrial motor drives, inverters, UPS systems, and renewable energy applications for high-power switching control.

Q2: What is the NGDR-07C NGDR-07 FF650R17IE4 gate charge of the module?
A2: The NGDR-07C NGDR-07 FF650R17IE4 gate charge is 7.00 μC, helping provide efficient switching performance.

Q3: What is the NGDR-07C NGDR-07 FF650R17IE4 internal gate resistor value?
A3: The NGDR-07C NGDR-07 FF650R17IE4 internal gate resistor is 2.3 Ω, which helps reduce switching noise and improve stability.

Q4: What is the NGDR-07C NGDR-07 FF650R17IE4 input capacitance of the module?
A4: The NGDR-07C NGDR-07 FF650R17IE4 input capacitance is 54.0 nF.

Q5: What is the NGDR-07C NGDR-07 FF650R17IE4 reverse transfer capacitance?
A5: The NGDR-07C NGDR-07 FF650R17IE4 reverse transfer capacitance is 1.70 nF, helping improve switching reliability.
