Product Specifications

Part Number	330195-02-12-50-05
Probe Specification	8mm probe
Thread Standard	3/8-24 UNF
Overall Length	5.0m
Certification	CSA、ATEX、IECEx
Output Resistance	50Ω
Radial Vibration Gap Voltage	-9VDC
Cable Capacitance	69.9pF/m
Field Wiring Gauge	0.2~1.5mm²（16~24AWG）

The system provides an output voltage that is directlyproportional to the distance between the probe tip and theobserved conductive surface and can measure both static(position) and dynamic (vibration) values. The system'sprimary applications are vibration and position measurements on fluid-film bearing machines, as well asKeyphasor reference and speed measurements3.
The 3300 XL 8 mm system delivers the most advancedperformance in our eddy current proximity transducersystems. The standard 3300 XL 8 mm 5-meter system alsofully complies with the American Petroleum Institute's (API)670 Standard for mechanical configuration, linear range,accuracy, and temperature stability. All 3300 XL 8 mmproximity transducer systems provide this level ofperformance and support complete interchangeability ofprobes, extension cables, and Proximitor sensors, eliminatingthe need to match or bench calibrate individual components.

Frequently asked questions：

Q1: What is the Bently Nevada 330195-02-12-50-05 used for?
A1: Bently Nevada 330195-02-12-50-05 is a 3300 XL 8 mm proximity probe used for non-contact vibration and shaft position monitoring in rotating machinery. It is commonly applied in machinery protection and condition monitoring systems.

Q2: What thread standard does the 330195 proximity probe use?
A2: The 330195-02-12-50-05 probe uses a 3/8-24 UNF thread standard for secure mounting and installation.

Q3: What is the 330195-02-12-50-05 overall length of the probe?
A3: The overall cable length of the 330195-02-12-50-05 is 5.0 meters.

Q4: What is the 330195-02-12-50-05 output resistance of this proximity probe?
A4: The 330195-02-12-50-05 output resistance is 50 Ω.

Q5: What is the 330195-02-12-50-05 radial vibration gap voltage of the probe?
A5: The 330195-02-12-50-05 radial vibration gap voltage is -9 VDC.

Product Applications

Oil & Gas
Power Generation
Chemical Plants
Steel & Metallurgy
Machinery Equipment
