Product Specifications

Manufacturer	GE FANUC
Product Number	IC200PWR002G
Product Type	Power Supply Module
Input Voltage	24 VDC
Output Voltage	5 VDC, 3.3 VDC
Input Power	11 W
Holdup Time	10 ms
Inrush Current	20 A @ 24 VDC；25 A @ 30 VDC
Protection Function	Short circuit, overload, reverse polarity protection
Max Total Output Current	1.5 A
Max 3.3 V Output Current	0.25 A
5 V Output Current Limit	1.5 A minus the consumed 3.3 V current (maximum)

The VersaMax IC200PWR002G is an Power Supply Module produced by General Electric Fanuc. This module’s job is to supply power to the following types of backplane devices: CPUs, NIUs, I/O modules, and more. When connected to the central processing unit or network interface unit, this power supply module acts as main power, but it can also be mounted to a booster carrier and act as supplementary power.
The IC200PWR002G uses direct current for its input and output voltage. For this device, the input voltage can vary between 18 volts and 30 volts DC. The nominal input voltage is 24 volts DC. The input power for this power unit is 11 watts, and the inrush current is rated at 20 and 25 amperes at 24 and 30 volts DC, respectively. Hold up time for this module is measured at approximately 10 milliseconds.
Output voltage for the IC200PWR002G is both 3.3 and 5 volts DC, and the output current is determined by the combination of both the 3.3 and 5-volt output voltage; however, output current shouldn’t go beyond 1.5 amperes.
The IC200PWR002G has options for protection against short circuits, overloads, and reverse polarity. When field wiring this power unit, ensure that the DC- is grounded to the frame ground and earth ground. Note: The DC- is grounded to the frame from within the power supply unit itself. As a result, a floating power supply configuration is not possible.

Frequently asked questions：

Q1: What is the GE IC200PWR002G Power Supply Module used for?
A1: The GE IC200PWR002G Power Supply Module is designed to provide stable DC power to PLC and system components. It converts incoming power into regulated outputs required by VersaMax control systems and associated I/O modules.

Q2: What is the input voltage of the IC200PWR002G?
A2: The IC200PWR002G module operates from a 24 VDC input voltage, making it suitable for standard industrial control power systems.

Q3: What is the IC200PWR002G input power requirement?
A3: The IC200PWR002G module requires approximately 11 W of input power during normal operation.

Q4: What is the holdup time of the IC200PWR002G power supply?
A4: The IC200PWR002G power supply offers a 10 ms holdup time, helping maintain operation during brief input power interruptions.

Product Applications

Oil and Gas
Power Systems
Water Treatment and Pumping Stations
Metallurgy and Steel
