Product Specifications

Model Number	HIMAX X-AI3201
Ambient temperature	0…+60 °C
Storage temperature	-40…+85 °C
Pollution degree	Pollution degree II in accordance with IEC/EN 61131-2
Altitude	< 2000 m
Housing Standard	IP20
Supply voltage	24 VDC
Number of transmitter supplies	32
Output voltage for transmitter supply	26.5 VDC +0/-15 %
Output current of transmitter supply	max. 30 mA
Nominal range	0/4…20 mA
Operating range	0…22.5 mA
Digital resolution	12-bit
Shunt for current measurement	200 Ω
Maximum permitted current via shunt	50 mA
Withstand voltage of the input	≤ 10 VDC
Interference voltage suppression	> 60 dB (common mode 50/60 Hz)

Frequently asked questions：

Q1: What is the HIMA HIMAX X-AI3201?
A1: The X-AI3201 is an analog input module for HIMA HIMAX safety systems, designed to acquire and process multiple analog signals from transmitters in safety-critical applications.

Q2: What is the X-AI3201 supply voltage?
A2: The X-AI3201 module operates on 24 VDC.

Q3: How many transmitter supplies are available?
A3: It provides up to 32 transmitter supplies for connected sensors.

Q4: What is the X-AI3201 operating current range?
A4: The X-AI3201 module supports an operating range of 0…22.5 mA.

Q5: What is the X-AI3201 digital resolution?
A5: It features 12-bit digital resolution for precise signal measurement.

Product Applications

Oil & Gas
Chemical & Fine Chemical
Power Generation
