Product Specifications

Supply voltage	24 VDC, -15 %…+20 %, rP ≤ 5 %, SELV, PELV
Current input min.	0.5 A (idle)
Continuous load max.	12 A at 24 VDC
Operating temperature	0…+60 °C
Storage temperature	-40…+85 °C
Humidity	max. 95 % relative humidity, non-condensing
Type of protection	IP20
Voltage drop (with high level)	1.3 V at 0.75 A output current
Nominal rated current (with high level)	0.5 A, range 0…0.6 A
Total current permitted for the module	12 A
Leakage current (with low level)	20 µA
Current limiting in the event of short-circuit	2 A, each channel
Inductive load	10 H
Capacitive load	100 µF
Lamp load (24 V)	4 W
SC Limit	0.8 A, range 0.8…0.85 A
Dimensions (H × W × D)	310 × 29.2 × 230 mm
Weight	approx. 1.1 kg

Frequently asked questions：

Q1: What is the HIMA HIMAX X-DI3201?
A1: The X-DI3201 is a digital input module for HIMA HIMAX safety systems, designed to receive and process discrete signals from industrial sensors and switches.

Q2: What is the X-DI3201 minimum current input?
A2: The X-DI3201 module requires a minimum idle current of 0.5 A.

Q3: What is the X-DI3201 maximum continuous load?
A3: The X-DI3201 module supports up to 12 A continuous load at 24 VDC.

Q4: What is the X-DI3201 operating temperature range?
A4: It operates between 0°C and +60°C.

Q5: What is the X-DI3201 total current permitted for the module?
A5: The X-DI3201 maximum total current for the module is 12 A.

Product Applications

Oil & Gas
Refining & Petrochemical
Power Generation
Process Industries
