Product Specifications

Part Number	6AV6545-0DB10-0AX0
Display Type	TFT display, 256 colors
Screen Diagonal	15.1 in
Horizontal Resolution	1024 Pixel
Vertical Resolution	768 Pixel
Backlight MTBF (25 °C)	50 000 h
Rated Current Consumption	1.8 A
Inrush Starting Current I²t	0.5 A²·s
Typical Active Input Power	41 W
Memory Type	Flash / RAM
User Data Available Memory	7 168 kbyte
Minimum Data Backup Time	3 years
Supported Online/Runtime Languages	5
Languages Per Single Project	32
Total Recipe Quantity	500
Data Records Per Recipe	1 000
Entries Per Data Record	1 000
Recipe Storage	128 KB integrated Flash, expandable

The SIEMENS SIMATIC MULTIPANEL MP 370 (Order Number: 6AV6545-0DB10-0AX0) is a high-end human-machine interface (HMI) engineered for heavy-duty industrial operator control and process visualization. The unit features a premium 15.1-inch color TFT display with an active viewing area of 308 mm × 232 mm, delivering a 1024 × 768 pixel (XGA) resolution and 256 colors for clear, comprehensive graphical presentation of intricate machine operations and plant piping diagrams.

In terms of electrical and hardware specifications, the 6AV6545-0DB10-0AX0 operates from a standard 24 V DC power supply with a flexible permissible tolerance range of +20.4 to +28.8 V DC. It draws a rated current of 1.8 A with a typical power consumption of 41 W, while maintaining a minimal starting inrush current (I²t) of just 0.5 A²⋅ s. To safeguard process data against sudden power grid failures, a serial UPS connection is natively supported, and an optional 3.6 V backup battery can be installed to provide a minimum data and real-time clock buffering duration of 3 years. Powered by an industrial MIPS processor, the system utilizes integrated Flash and RAM memory types, provisioning 7168 KB of usable memory for user data and an additional 5689 KB of separate memory reserved for specialized system options.

Frequently asked questions：

Q: What type of operator panel is Siemens 6AV6545-0DB10-0AX0?
A: Siemens 6AV6545-0DB10-0AX0 is a SIMATIC Multi Panel MP 370 with a 15.1-inch color TFT display and touch operation for industrial control and visualization

Q: How large is the display on 6AV6545-0DB10-0AX0?
A: The display measures 15.1 inches diagonally, with a display size of 308 mm × 232 mm and a resolution of 1024 × 768 pixels

Q: Can 6AV6545-0DB10-0AX0 connect to a UPS?
A: Yes. 6AV6545-0DB10-0AX0 supports a serial UPS connection for suitable system configurations

Q: What power supply does Siemens 6AV6545-0DB10-0AX0 require?
A: The panel uses 24 V DC, with a permissible supply range of +20.4 to +28.8 V DC and a rated current of 1.8 A
